Product Introduction

Main

Range of Product

Modicon Quantum automation platform

Product or Component Type

RIO drop adaptor module

Complementary

Product Compatibility

Quantum

Maximum Number of I/O Expansion Module

27

Type of cable

75 Ohm coaxial

Transmission Rate

1544 Mbit/s

Dynamic range

35 dB

Isolation voltage

500 V DC coaxial center and ground

Electrical connection

1 female connector F, elbowed with single cable

Diagnostics startup

Executive checksum

RAM address/data

Power up and runtime

Power dissipation in W

3 W 1 channel

Bus current requirement

600 mA 1 channel

Module format

Standard

Environment

Resistance to electrostatic discharge

4 kV contact IEC 801-2

8 kV on air IEC 801-2

Resistance to electromagnetic fields

9.1 V/m (10 V/m) 80…1000 MHz IEC 801-3

Ambient Air Temperature for Operation

32…140 °F (0…60 °C)

Ambient Air Temperature for Storage

-40…185 °F (-40…85 °C)

Relative Humidity

95 % without condensation

Operating altitude

<= 16404.2 ft (5000 m)
